Specifications

Engine

Engine Model	C1.7 Turbo
Net Power @ 2,400 rpm - ISO 9249, 80/1269/EEC	33.6 kW
Gross Power @ 2,400 rpm - SAE J1995:2014	36.1 kW
Bore	84.0 mm
Stroke	100.0 mm
Displacement	1.662 L

Weights

Operating Weight with Canopy	4996 kg (Min), 5655 kg (Max)
Operating Weight with Cab	5095 kg (Min), 5754 kg (Max)

Weight Increase from Minimum Configuration

Counterweight	242 kg
Long Stick	34 kg
Steel Tracks with Pads	375 kg
Angle Blade	102 kg

Travel System

Travel Speed – High	5.0 km/h
Travel Speed – Low	2.8 km/h
Maximum Traction Force – High Speed	24.7 kN
Maximum Traction Force – Low Speed	50.5 kN
Ground Pressure – Minimum Weight	27.3 kPa
Ground Pressure – Maximum Weight	32.2 kPa
Gradeability (maximum)	30 degrees

Service Refill Capacities

Cooling System	11.0 L
Engine Oil	6.0 L
Fuel Tank	68.0 L
Hydraulic Tank	60.0 L
Hydraulic System	75.0 L

Hydraulic System

Pump Flow @ 2,400 rpm	133 L/min
Operating Pressure – Equipment	265 bar
Operating Pressure – Travel	265 bar
Operating Pressure – Swing	200 bar
Auxiliary Circuit – Primary - Flow	80 L/min
Auxiliary Circuit – Primary - Pressure	265 bar
Auxiliary Circuit – Secondary - Flow	28 L/min
Auxiliary Circuit – Secondary - Pressure	265 bar
Digging Force – Stick (standard)	28.3 kN
Digging Force – Stick (long)	25.2 kN
Digging Force – Bucket	49.2 kN

Swing System

Machine Swing Speed	9.0 rpm
Boom Swing – Left	72 Degrees
Boom Swing – Right	50 Degrees

Blade

Width (Straight)	1980 mm
Height (Straight)	390 mm
Width (Angle)	1980 mm
Height (Angle)	400 mm
Angle Blade – Left	25 degrees
Angle Blade – Right	25 degrees

Certification – Cab and Canopy

Roll Over Protective Structure (ROPS)	ISO 12117-2:2008
Top Guard	ISO 10262:1998 Level I

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
